• Able to drive and orientate the turret at the same time
• Tight turning radius
• Zero tailswing
• Compact stowed height passes through standard doorways doorways
• 1.20m width

Working height	11.7 m
Platform height	9.7 m
Horizontal outreach	7.22 m
Up and over clearance	4.74 m
Lift capacity	230 kg
Platform size	1.15 x 0.8 m
Length	5.64 m
Width	1.2 m
Height - stowed	1.99 m
Transport length	4.2 m
Transport height	2.6 m
Tailswing	0 cm
Horizontal jib rotation	180° (-90/+90)
Vertical jib rotation	140° (-70/+70
Platform rotation	180° (-90/+90)
Turntable rotation	355 °
Wheelbase:1.65 m
Ground clearance	10.7 cm
Tilt:3 °
Proportional drive speed	0.7 - 6 km/h
Gradeability	25 %
Turning radius - outside	3.6 m
Tyres - non marking	600x190
Energy	48V - 320 Amph (C5)
Weight	7040 kg
