URW 547
The UNIC URW 547 is a compact crawler (spider) crane offering 4 t lifting capacity, 18.2 m hook height and 17.83 m working radius. Big lifting power in tight spaces.
- Lifting capacity
- 4 t
- Hook height
- 18.2 m
- Working radius
- 17.83 m
- Machine weight
- 5.01 t
- CE compliant, safe lifting with safe load indicator (SLI)
- Mobile service and periodic maintenance
- Certified operator training on delivery
Key features
Why choose the URW 547?
- Computer-controlled moment limiter (safe load indicator)
- Remote control
- Over-hoist alarm
- Computer-controlled smart voice warning system
- Multi-function operation via remote control
- Smart throttle activation
- Automatic hook stowing
- Overload warning device
- Overload warning lamps
- Working area limitation
Lifting geometry
18.2 m Hook height
Scale: based on a 1.8 m human figure.
UNIC · Spider Cranes
Technical specifications
UNIC URW 547
Values are based on manufacturer data and may vary with options and configuration.
Download brochure (PDF)| Crane capacity | 4.0 t at 2.5 m |
|---|---|
| Max. working radius | 17.83 m |
| Max. working height | 18.2 m |
| Machine dimensions | 4955 mm x 1400 mm x 1980 mm |
| Machine weight | 5010 kg |
| Winch speed | 14 m/min |
| Telescopic boom length | 3.99 - 18.02 m |
| Turret rotation | 360° |
| Max. gradeability | 23° |
| Drive speed (km/h) | 0 - 3 |
| Mitsubishi engine | 17.5 kW (23.8 PS) |
| Electric motor | 7.5 kW 400V |
FAQ
Questions about the URW 547
What is the lifting capacity of the UNIC URW 547?
The UNIC URW 547 lifts up to 4 t, with 18.2 m hook height and 17.83 m working radius.
Can the UNIC URW 547 be used indoors?
Yes. The diesel + electric UNIC URW 547 is suitable for indoor use and can also work outdoors.
Where can I buy the UNIC URW 547 in Türkiye?
Acarlar Makine is the official UNIC distributor in Türkiye. It provides sales, 24/7 technical service, genuine spare parts and operator training for the URW 547 across the country. For price and delivery time, fill in the quote form or call +90 216 581 49 49.
